Photocells / Photosensors Alutech LM-L
#004696
€65.00
✓ Available
✗ Not available
Description:
Alutech Lumino LM-L is a compact and reliable photocell kit used in gate automation and barrier systems. Its main function is to prevent the gate leaf or barrier boom from colliding with an obstacle by automatically stopping or causing the gate to open if the invisible infrared beam is interrupted.
- Operating range: not less than 12 meters (provides protection even for very wide gates).
- Power supply voltage: 12 V to 24 V AC / DC (alternating current or direct current)
- Current consumption: Transmitter (TX): ≤ 15 mA; Receiver (RX): ≤ 30 mA
- Output contacts: Relay with NC (normally closed) and NO (normally open) contacts
- Maximum relay load: 1 A / max. 30 V DC
- Beam wavelength: infrared, 940 nm.
- Protection class: IP54
- Operating temperature: from -20°C to +60°C
